Input |
1/4" Unbalanced (Tip-Sleeve) |
Max Input Level |
+5 dBu |
Input Impedance |
1 MΩ (Effect enabled or effect bypassed w/ Momentary switch on) True Bypass (Effect bypassed w/ Momentary switch off) |
Output |
1/4" Unbalanced (Tip-Sleeve) |
Max Output Level |
+10 dBu |
Output Impedance |
1 kΩ (Effect enabled or effect bypassed w/ Momentary switch on) True Bypass (Effect bypassed w/ Momentary switch off) |
Controls |
Ballistics Control, Pitch Control, Range Switch, Momentary Switch, Effect On/Off |
Sample Rate |
44.1 kHz in classic mode, 22 kHz in chords mode |
Frequency Response |
20 Hz–16 kHz (classic mode), 20 Hz–11 kHz (chords mode) |
Signal to Noise Ratio |
> -106dB (A weighted); ref = max level, 22 kHz bandwidth |
A/D/A Converter |
24-bit |
THD |
0.004% @ 1 kHz; ref = 1 dBu w/ unity gain |
Power Consumption |
2.1 Watts (235 mA typical @ 9 VDC) |
Power Requirements |
9 VDC External Adapter (sold separately) |
Power Supply |
PS0913DC-01 (US, JA, EU); PS0913DC-02 (AU, UK) |
Power Adapter Output |
9 VDC 1.3 A |
Weight |
0.36 lbs. (0.163 kgs.) |
Dimensions |
4.75” (L) x 2.875” (W) x 1.75” (H) |
