EMG-40J Active Single Coil Jazz Style Soapbar Pickup for 5-String Bass


Sold out.

 EMG created the Extended Series Bass Pickups to satisfy extreme bass string spacing requirements while delivering all the responsiveness and quietness that EMG is known for.

The EMG-40J model uses a single coil design which has a less powerful low end but a more prominent midrange. Featuring a very low ratio of resistance to inductance that increases the low frequency response, the EMG-40J still maintains the narrow aperture for that typical Jazz Bass tone. This pickup uses a 40 Extended housing that is 4 inches (102mm).

Package Includes: EMG's exclusive Quik-Connect„ cable, prewired solid shaft volume/tone control set, output jack, battery clip set, and adjustment screws.


Logo Color: Silver
Resonant Frequency (Khz) 4.8
RMS Output Voltage 0.8
Peak Output Voltage 1.10
Output Noise (dBV) -91
Output Impedance (Kohm) 10
Current @ 9V (Microamps) 80
Battery Life (Hours) 3000
Max Supply Voltage (VDC) 27
Max String Width (Inches) 3.125
