EMG created the Extended Series Bass Pickups to satisfy extreme bass string spacing requirements while delivering all the responsiveness and quietness that EMG is known for.
The 40P5 design has two offset coils that result in more low end with brilliant highs. It is intended for 5-string models that have a standard string spacing and uses short, squat coils that have very little resistance and plenty of inductance. Ceramic magnets are used to add clarity. The 40P5 has a natural presence, powerful lows, punchy midrange, and superior definition. This pickup uses a 40 Extended housing that is 4 inches (102mm).
Package Includes: EMG's exclusive Quik-Connect™ cable, prewired solid shaft volume/tone control set, output jack, battery clip set, and adjustment screws.
|Resonant Frequency (Khz)||4.5|
|RMS Output Voltage||1.0|
|Peak Output Voltage||1.40|
|Output Noise (dBV)||-90|
|Output Impedance (Kohm)||10|
|Current @ 9V (Microamps)||80|
|Battery Life (Hours)||3000|
|Max Supply Voltage (VDC)||27|
|Max String Width (Inches)||3.125|
